The drawing references include Cherry Shaker, Navy Blue, Timber Shaker, Sand Pebble, Weathered Grey and Unfinished. Use each sheet to identify a layout, then check exact code, current specifications and site clearances before approval.
Find your cabinet drawing
Search an item number or choose a cabinet type. Open the drawing to inspect it at full size.
8 matching drawing sheets
Base and sink cabinets
Open full-size drawing →
Item numbers on this drawing
B9 · B12 · B15 · B18 · B21 · B24 · B27 · B30 · B33 · B36 · B39 · B42 · B45 · B48 · SB24 · SB27 · SB30 · SB33 · SB36 · SB39 · SB42 · SB45 · SB48 · SB33 FARM · SB36 FARM · T-VSB2418 · T-VSB2421 · T-VSB2721 · T-VSB3018 · T-VSB3318 · T-VSB3021 · T-VSB3321
Cross-check each line item
Use a drawing as a dimension and configuration reference for one exact cabinet code. Compare width, height, depth and opening arrangement with the approved elevation. Mark the drawing version and the code beside the item schedule so a substitute or revised selection can be identified before release.
Review fillers, hinge clearance, appliance specifications and adjacent cabinets on the same sheet. A cabinet can have the right nominal width and still create a conflict at an exposed end or doorway. Resolve those conditions against field measurements and the current manufacturer specification.
Supplier reference received September 7, 2026. SKU ranges describe the drawing sheet; they do not confirm current stock.
